HEMENG COOLERS SYSTEM
FOr SPAL Blower Motor fan 12V evaporator radial RA3VCV / 011-A45-22 / 011-A54/2C/1-22 / 3000.4511 / 011-A54/1-22 / 011-A54-22 / 3000.4501 / 011-A46-22
FOr SPAL Blower Motor fan 12V evaporator radial RA3VCV / 011-A45-22 / 011-A54/2C/1-22 / 3000.4511 / 011-A54/1-22 / 011-A54-22 / 3000.4501 / 011-A46-22
Regular price
$60.00 USD
Regular price
Sale price
$60.00 USD
Quantity
Couldn't load pickup availability
Performance chart
| Static pressure | Static pressure | Airflow | Current draw | Airflow | Static pressure |
|---|---|---|---|---|---|
| Pa | mm H₂0 | m³/h | A | CFM | in H₂0 |
| 0.0 | 0.0 | 864.0 | 14.6 | 508.0 | 0.0 |
| 49.0 | 5.0 | 814.0 | 13.9 | 479.0 | 0.2 |
| 100.0 | 10.0 | 769.0 | 13.5 | 452.0 | 0.4 |
| 150.0 | 15.0 | 716.0 | 12.8 | 421.0 | 0.6 |
| 199.0 | 20.0 | 663.0 | 12.2 | 390.0 | 0.8 |
| 249.0 | 25.0 | 601.0 | 11.4 | 354.0 | 1.0 |
| 300.0 | 31.0 | 542.0 | 10.8 | 319.0 | 1.2 |
| 348.0 | 36.0 | 459.0 | 9.9 | 270.0 | 1.4 |
| 403.0 | 41.0 | 311.0 | 8.2 | 183.0 | 1.6 |
| 445.0 | 45.0 | 174.0 | 6.6 | 102.0 | 1.8 |
| 493.0 | 50.0 | 90.0 | 6.1 | 53.0 | 2.0 |
| 525.0 | 54.0 | 0.0 | 6.0 | 0.0 | 2.1 |
